HTTPS证书生成原理和部署细节

# 生成服务器端私钥
openssl genrsa -out server.key 1024
# 生成服务器端公钥
openssl rsa -in server.key -pubout -out server.pem


# 生成客户端私钥
openssl genrsa -out client.key 1024
# 生成客户端公钥
openssl rsa -in client.key -pubout -out client.pem

# 生成 CA 私钥
openssl genrsa -out ca.key 1024
# X.509 Certificate Signing Request (CSR) Management.
openssl req -new -key ca.key -out ca.csr
# X.509 Certificate Data Management.
openssl x509 -req -in ca.csr -signkey ca.key -out ca.crt

➜  keys  openssl req -new -key ca.key -out ca.csr
You are about to be asked to enter information that will be incorporated
into your certificate request.
What you are about to enter is what is called a Distinguished Name or a DN.
There are quite a few fields but you can leave some blank
For some fields there will be a default value,
If you enter '.', the field will be left blank.
-----
Country Name (2 letter code) [AU]:CN
State or Province Name (full name) [Some-State]:Zhejiang
Locality Name (eg, city) []:Hangzhou
Organization Name (eg, company) [Internet Widgits Pty Ltd]:My CA
Organizational Unit Name (eg, section) []:
Common Name (e.g. server FQDN or YOUR name) []:localhost
Email Address []:

# 服务器端需要向 CA 机构申请签名证书，在申请签名证书之前依然是创建自己的 CSR 文件
openssl req -new -key server.key -out server.csr
# 向自己的 CA 机构申请证书，签名过程需要 CA 的证书和私钥参与，最终颁发一个带有 CA 签名的证书
openssl x509 -req -CA ca.crt -CAkey ca.key -CAcreateserial -in server.csr -out server.crt

# client 端
openssl req -new -key client.key -out client.csr
# client 端到 CA 签名
openssl x509 -req -CA ca.crt -CAkey ca.key -CAcreateserial -in client.csr -out client.crt

.
├── https-client.js
├── https-server.js
└── keys
    ├── ca.crt
    ├── ca.csr
    ├── ca.key
    ├── ca.pem
    ├── ca.srl
    ├── client.crt
    ├── client.csr
    ├── client.key
    ├── client.pem
    ├── server.crt
    ├── server.csr
    ├── server.key
    └── server.pem

// file http-server.js
var https = require('https');
var fs = require('fs');

var options = {
  key: fs.readFileSync('./keys/server.key'),
  cert: fs.readFileSync('./keys/server.crt')
};

https.createServer(options, function(req, res) {
  res.writeHead(200);
  res.end('hello world');
}).listen(8000);

➜  https  curl https://localhost:8000
curl: (60) SSL certificate problem: Invalid certificate chain
More details here: http://curl.haxx.se/docs/sslcerts.html

curl performs SSL certificate verification by default, using a "bundle"
 of Certificate Authority (CA) public keys (CA certs). If the default
 bundle file isn't adequate, you can specify an alternate file
 using the --cacert option.
If this HTTPS server uses a certificate signed by a CA represented in
 the bundle, the certificate verification probably failed due to a
 problem with the certificate (it might be expired, or the name might
 not match the domain name in the URL).
If you'd like to turn off curl's verification of the certificate, use
 the -k (or --insecure) option.

➜  https  curl -k https://localhost:8000
hello world%

// file http-client.js
var https = require('https');
var fs = require('fs');

var options = {
  hostname: "localhost",
  port: 8000,
  path: '/',
  methed: 'GET',
  key: fs.readFileSync('./keys/client.key'),
  cert: fs.readFileSync('./keys/client.crt'),
  ca: [fs.readFileSync('./keys/ca.crt')]
};

options.agent = new https.Agent(options);

var req = https.request(options, function(res) {
  res.setEncoding('utf-8');
  res.on('data', function(d) {
    console.log(d);
  });
});
req.end();

req.on('error', function(e) {
  console.log(e);
});

➜  https  node https-client.js
hello world

server_names barretlee.com *.barretlee.com
ssl on;
ssl_certificate /etc/nginx/ssl/barretlee.com.crt;
ssl_certificate_key /etc/nginx/ssl/barretlee.com.key;
ssl_protocols TLSv1 TLSv1.1 TLSv1.2;
ssl_ciphers "EECDH+ECDSA+AESGCM EECDH+aRSA+AESGCM EECDH+ECDSA+SHA384EECDH+ECDSA+SHA256 EECDH+aRSA+SHA384 EECDH+aRSA+SHA256 EECDH+aRSA+RC4EECDH EDH+aRSA RC4 !aNULL !eNULL !LOW !3DES !MD5 !EXP !PSK !SRP !DSS !MEDIUM";
# Add perfect forward secrecy
ssl_prefer_server_ciphers on;
add_header Strict-Transport-Security "max-age=31536000; includeSubdomains";
